Installation Instructions

3 Switches & 1 Fan (3S1F) Module - Installation


Prerequisite before installation

  • 4 module Metal Box is required
  • Metal box size: 135mm x 78mm (5"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load F - Fan N - Neutral P - Phase Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. Loop the two phases using a piece of wire. While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 3: Use the screws provided to fix the device to the console box. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on. Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • Do not connect any load greater than 6A. Each light switch is rated to 6A resistive only.
  • Do not connect loads in series to one light switch. Only a max of 40 W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Each Fan / Dimmer switch is capable of supporting a maximum of 200 W resistive load or a maximum of 100 W Fan / Inductive load only.
  • Do not connect LED or CFL fixtures to the Fan / Dimmer switch.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




4 Switches (4S) Module - Installation


Prerequisite before installation

  • 4 module Metal Box is required
  • Metal box size: 135mm x 78mm (5"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load N - Neutral P - Phase Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 3: Use the screws provided to fix the device to the console box. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on. Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • Do not connect any load greater than 6A. Each light switch is rated to 6A resistive only.
  • Do not connect loads in series to one light switch. Only a max of 40 W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




2 Switches (2S) Module - Installation


Prerequisite before installation

  • 2 module Metal Box is required
  • Metal box size: 78mm x 78mm (3"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load N - Neutral P - Phase Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Loop the two phases using a piece of wire. While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 3: Use the screws provided to fix the device to the console box. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on. Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • Do not connect any load greater than 6A. Each light switch is rated to 6A resistive only.
  • Do not connect loads in series to one light switch. Only a max of 40 W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




1 Switch (1S - 16 Amps) Module - Installation


Prerequisite before installation

  • 2 module Metal Box is required
  • Metal box size: 78mm x 78mm (3"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load N - Neutral P - Phase Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Loop the two phases using a piece of wire. While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 3: Use the screws provided to fix the device to the console box. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on. Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • Do not connect any load greater than 16A. Each light switch is rated to 16A resistive only.
  • Do not connect loads in series to one light switch.
  • This device is not suitable for single phase motor pumps as the starting current is 6 times that of the rated load current, which may cause relay contacts to permanently weld.




3 Switches & 1 Fan & Plug (3S1F1P) Module - Installation


Prerequisite before installation

  • 8 module Metal Box is required
  • Metal box size: 233mm x 78mm (9"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load F - Fan N - Neutral P1 - EB/UPS P2 - EB P3 - Plug Phase E - Earth P1 Powers - F, L1 P2 Powers - L2, L3 Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Note: If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. If you want a socket with UPS power source loop P3 to UPS. Step 3: Use the screws provided to fix the device to the console box. Note: While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on. Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • For Loads L1 to L3, Do not connect loads greater than 6A. Each light switch is rated upto 6A resistive only.
  • For Socket, Do not connect load greater than 6A. Socket is rated upto 6A resistive only.
  • Do not connect loads in series to one light switch. Only a maximum of 40W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Each Fan switch is capable of supporting a maximum of 200W resistive load or a maximum of 100W Fan / Inductive load only.
  • Do not connect LED or CFL fixtures to the Fan switch.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




6 Switches & 2 Fan (6S2F) Module - Installation


Prerequisite before installation

  • 8 module Metal Box is required
  • Metal box size: 233mm x 78mm (9"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load F - Fan N - Neutral P1 - EB/UPS P2 - EB P1 Powers - F1, F2, L1, L2 P2 Powers - L3, L4, L5, H(High Load) Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Note: If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. Connect High loads to H. Step 3: Use the screws provided to fix the device to the console box. Note: While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on.​ Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • For Loads L1 to L5, Do not connect loads greater than 6A. Each light switch is rated upto 6A resistive only.
  • For Load H, Do not connect loads greater than 16A. High Load switch is rated upto 16A resistive only.
  • Do not connect loads in series to one light switch. Only a maximum of 40W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Each Fan switch is capable of supporting a maximum of 200W resistive load or a maximum of 100W Fan / Inductive load only.
  • Do not connect LED or CFL fixtures to the Fan switch.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




7 Switches & 1 Fan (7S1F) Module - Installation


Prerequisite before installation

  • 8 module Metal Box is required
  • Metal box size: 233mm x 78mm (9"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load F - Fan N - Neutral P1 - EB/UPS P2 - EB P1 Powers - F, L1, L2, L3 P2 Powers - L4, L5, L6, H(High Load) Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Note: If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. Connect High loads to H. Step 3: Use the screws provided to fix the device to the console box. Note: While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on.​ Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • For Loads L1 to L6, Do not connect loads greater than 6A. Each light switch is rated upto 6A resistive only.
  • For Load H, Do not connect load greater than 16A. High Load switch is rated upto 16A resistive only.
  • Do not connect loads in series to one light switch. Only a maximum of 40W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
  • Each Fan switch is capable of supporting a maximum of 200W resistive load or a maximum of 100W Fan / Inductive load only.
  • Do not connect LED or CFL fixtures to the Fan switch.
  • Take extra precaution while connecting phase and neutral wires to the device and the load.




8 Switches (8S) Module - Installation


Prerequisite before installation

  • 8 module Metal Box is required
  • Metal box size: 233mm x 78mm (9"x3")
  • Touch switch
  • Console screws
  • Flat-headed screwdriver
Step 1: Detach the front glass panel carefully from the switch module using a screwdriver. Step 2: L - Load F - Fan N - Neutral P1 - EB/UPS P2 - EB P1 Powers - L1, L2, L3, L4 P2 Powers - L5, L6, H1 & H2(High Load) Follow the wiring diagram and connect the phase, neutral and load wires to the switch module terminals. Note: If you want to separate loads between UPS and EB connect P1 to UPS and P2 to EB. If no separation is required, loop P1 & P2 and connect to EB or UPS. Connect High loads to H1 & H2. Step 3: Use the screws provided to fix the device to the console box. Note: While inserting the wire into the terminal make sure the copper ends are tightly twisted. Step 4: Clip the front panel to the device and turn the power ON. Note: Due to change in capacitance, the switch may become unresponsive after fixing the glass panel. Please turn off the main power and turn it back on.​ Safety Warnings:
  • Do not install the device without turning off the main power supply.
  • Do not connect the glass panel without turning off the main power supply.
  • For Loads L1 to L5, Do not connect loads greater than 6A. Each light switch is rated upto 6A resistive only.
  • For Load H1 & H2, Do not connect loads greater than 16A. Each High Load switch is rated upto 16A resistive only.
  • Do not connect loads in series to one light switch. Only a maximum of 40W is supported in cases of LED & CFL fitting. Anything more may weld the switch contacts and leave the load in a permanently ON state.
